ประเภท
|
จํานวนช่องอากาศ
|
DIa. ((mm)
|
น้ําหนัก ((kg)
|
ปุ่มวัด
|
ปุ่มด้านหน้า
|
การจับคู่ DTH Hammer
|
|
GL65PQ
|
1
|
68-72
|
1.5
|
4×Φ12
|
3 × Φ12
|
GL65
|
|
GL75PQ
|
3
|
75-77
|
2.4
|
5 × Φ12
|
3 × Φ12
|
GL70
|
|
GL76PQ
|
2
|
76-78
|
2.5
|
5 × Φ12
|
3 × Φ12
|
GL76
|
|
GL76-78
|
2
|
78-82
|
2.6
|
5 × Φ12
|
3 × Φ12
|
|
|
GL80PQ
|
3
|
82-84
|
3
|
5 × Φ12
|
6×Φ12
|
GL80 /80X
|
|
GL90A
|
3
|
90-95
|
3.6
|
6×Φ12
|
4×Φ12
|
|
|
GL80XD-90
|
3
|
90-95
|
3.4
|
6×Φ12
|
4×Φ12
|
GL80XD
|
|
GL80-II-80
|
3
|
80-82
|
3
|
5 × Φ12
|
4×Φ12
|
GL80-II
|
|
GL90B
|
3
|
90-95
|
3.8
|
6×Φ12
|
4×Φ12
|
GL90/90-I
|
|
GL90T1
|
2
|
90-95
|
3.6
|
6×Φ14
|
1 × Φ12
|
|
|
3 × Φ12
|
||||||
|
GL90T2
|
2
|
90-95
|
3.8
|
6×Φ12
|
4×Φ12
|
|
|
GL90T3J
|
3
|
90-95
|
3.6
|
6×Φ12
|
4×Φ12
|
|
|
GL90T5
|
2
|
90-95
|
3.6
|
5 × Φ12
|
4×Φ12
|
|
|
GL90-100
|
3
|
100-105
|
4
|
6×Φ12
|
5 × Φ12
|
|
|
GL90-105
|
3
|
105-110
|
4.2
|
6×Φ14
|
5 × Φ12
|
|
|
GL90-110
|
3
|
110-115
|
4.5
|
8×Φ14
|
3 × Φ12
|
|
|
GL90-120
|
3
|
120-125
|
5
|
8×Φ14
|
3 × Φ12
|
|
|
GL90-130
|
3
|
130-135
|
6.8
|
9 × Φ14
|
4×Φ12
|
|
|
GL110-110
|
3
|
110-115
|
6.1
|
6×Φ14
|
5 × Φ12
|
GL110
|
|
GL110-115
|
3
|
110-115
|
6.3
|
6×Φ14
|
5 × Φ12
|
|
|
GL110-120
|
3
|
120-125
|
7
|
6×Φ14
|
6×Φ12
|
|
|
GL110-125
|
3
|
125-130
|
7.1
|
6×Φ14
|
7×Φ12
|
|
|
GL110-130
|
3
|
130-135
|
7.3
|
6×Φ14
|
7×Φ12
|
|
|
GL110-135
|
3
|
135-140
|
8
|
6×Φ14
|
7×Φ12
|
|
|
GL110-140
|
3
|
140-145
|
8.2
|
6×Φ14
|
8×Φ12
|
|
|
GL110-150
|
3
|
150-155
|
9
|
6×Φ14
|
8×Φ12
|
|
|
GL150-155
|
3
|
155-160
|
16.3
|
15 × Φ16
|
4×Φ14
|
GL150
|
|
GL150-165
|
3
|
160-165
|
17.3
|
15 × Φ16
|
5×Φ14
|
|
|
GL150-185
|
3
|
180-185
|
19.6
|
15 × Φ16
|
6×Φ14
|
|
|
GL150-200
|
3
|
200-205
|
23
|
9×Φ16
|
12 × Φ14
|
|
|
GL170-175
|
3
|
175-180
|
22.8
|
15 × Φ16
|
8×Φ14
|
GL170
|
|
GL170-185
|
3
|
185-190
|
23.24
|
15 × Φ16
|
8×Φ14
|
|
|
GL170-195
|
3
|
195-198
|
24
|
15 × Φ16
|
10 × Φ14
|
|
|
GL170-200
|
3
|
200-203
|
25.8
|
15 × Φ16
|
9 × Φ14
|
|
|
GL170-210
|
3
|
210-213
|
26.5
|
12 × Φ16
|
6×Φ14
|
|
|
6×Φ16
|
||||||
|
GL170-220
|
3
|
220-223
|
28.5
|
15 × Φ16
|
11 × Φ14
|
|
|
GL170-230
|
3
|
230-233
|
32
|
15 × Φ16
|
12 × Φ14
|
|
|
GL170-240
|
3
|
240-243
|
36
|
21 × Φ16
|
6×Φ14
|
|
|
GL170-250
|
3
|
250-253
|
45
|
15 × Φ16
|
4×Φ14
|
|
|
ประเภท
|
จํานวนหลุม
|
DIa. ((mm)
|
น้ําหนัก ((kg)
|
ปุ่มวัด
|
ปุ่มด้านหน้า
|
การจับคู่ DTH Hammer
|
|
GL4.5-115
|
2
|
115-118
|
6.4
|
7×Φ14
|
6×Φ12
|
GL45
|
|
GL4.5-120
|
2
|
120-123
|
7
|
7×Φ14
|
6×Φ12
|
|
|
GL4.5-130
|
2
|
130-133
|
8
|
7×Φ14
|
6×Φ12
|
|
|
GL4.5-140
|
2
|
140-143
|
8.2
|
7×Φ14
|
6×Φ12
|
|
|
GL4.5-150
|
2
|
150-153
|
9
|
7×Φ14
|
6×Φ12
|
|
|
GL330-85
|
2
|
82-85
|
3.4
|
6×Φ14
|
3 × Φ12
|
GL330
|
